Aluminium Twin Track Fixing Plates

Twin track aluminium fixing plates are used as the linking mechanism to clamp PVC strips to aluminium twin track curtain rails. Each PVC strip requires its own fixing plate. Available in 200mm, 300mm and 400mm sizes. Supplied with free M8 nuts and bolts for fitting to rails. ALL SIZES NOMINAL.

Twin track aluminium fixing plates are versatile enough to take all sizes and specs of PVC and come complete with fixing nuts and bolts for attaching to your twin track rails. The bolts slide into the rail’s parallel mounting grooves. Once in your chosen position, PVC strips (prepped with holes in the right places) slot over the ends of the bolts. The fixing plates and M8 nuts are then used to clamp them securely in place.  TIP: The fixing plates can be used as a template for drilling the holes in your PVC strips.

Note:  If your strip curtain needs to withstand very heavy / repeated use by forklifts or other powered vehicles you may want to consider our Swivel-Hinge rail instead.

Available in: 200mm, 300mm & 400mm sizes. Suitable for curtains up to 10m high.

Note: All dimensions nominal. Subject to original manufacturer’s standard tolerances.

Key Details:

Hanging Format: Twin Track

Plate Set Size:  200mm, 300mm & 400mm

Material: Extruded aluminium

Size Fixing Holes: 8mm

Fixings: M8 nuts and bolts are supplied with the plates.

Recommended Traffic: Pedestrian, pump truck and very occasional / light weight forklift use.

Recommended Environments: General Pedestrian, Food & Catering, Commercial, Pest Control.

Longevity: This product’s lifespan will be dictated by where it’s used, what type of traffic might move through it and how carefully (or aggressively) such traffic does so. This is beyond any manufacturer’s or suppliers control. Used appropriately, the product should last for many years.
